Lazy Load Content With Svelte and Intersection Oberver

Imagine you are serving a bunch of content on a website. Let's assume you have a lot of high quality images like below

Scroll to see all images

Above images add up to more than 10MB! Loading this much data would definitely cause frictions in the user interface, especially for the users on low-data environments.

Svelte provides tools like enhanced:img that helps you serve images in formats like webp.

However, if you images are too big, this solution won't give you a complete work-around. This is where lazy loading comes into picture.

Lazy Loading

The idea behind the lazy loading is to wait loading the content until the user scrolls to it.

This way, we can load the content that's only visible in the viewport at first, and hold on loading others. This will drastically reduce the load time.

This idea can be implemented like below in Svelte.

{#each images as image}
 {#if scrolledToImage}
  <img src={image} />
 {/if}
{/each}

We can add fade in transitions, to give it a better user experience. This will make it seem like we are loading images as the user is scrolling, which is actually the case.

<script>
import { fade } from 'svelte/transition';
let images = [img1, img2, img3, ...]
let scrolls = [scrollForImg1, scrollForImg2, scrollForImg3, ...]
</script>

{#each images as image, index}
 {#if scrolls[index]}
  <div transition:fade={{ duration: 300 }}>
   <img src={image} />
  </div>
 {/if}
{/each}

For transitions to work in Svelte, they should enter the DOM and that's where the if statement helps us.

If statement is also the backbone of the lazy loading, as the elements that are not scrolled won't be rendered, so we will save resources.

Now let's see how we can determine whether the user has scrolled to the image in question, ie scrolledToImage. This is where we will use the Intersection Observer API.

Intersection Observer

I won't get into details, as it can be found in the above link, but what Intersection Observer does is, it fires an event when an item intersects another item. E.g. when we useviewport as the base item, intersection means whether the item is scrolled to.

The syntax is like below:

let callback = (entries, observer) => {
 entries.forEach((entry) => {
  if (entry.isIntersecting) {
   // load image
  }
 });
};

let observer = new IntersectionObserver(callback, { threshold: 0 });
// threshold:0 means any part of item is intersecting the viewport. I.e. the view is scrolled to.

observer.observe(element);

Note that IntersectionObserver should be called after the component is mounted in Svelte, because this object does not exist in the server and it will give error.

Bring It All Together

<script>
import { onMount } from 'svelte';
import { fade } from 'svelte/transition';

// Array that will keep the image divs
let divs = images.map(() => null);

// Array that will keep info about whether an image is scrolled to
let scrolls = images.map(() => false);

// Setup intersection observer when component is mounted
onMount(async () => {
 let callback = (entries, observer) => {
  entries.forEach((entry) => {
   if (entry.isIntersecting) {
    // we get the div id, which will point us to the right element in scrolls array
    scrolls[entry.target.id] = true;
   }
  });
 };

 // Set the rooter as the div with id "container" as that is the parent div of the images
 let observer = new IntersectionObserver(callback, { threshold: 0, root: document.querySelector('#container') });

 // Observe each div
 divs.forEach((d) => {observer.observe(d)});
});
</script>

// NOTE1: the parent div of each image needs to have an initial height. (E.g. 300px)
// Otherwise, they will be defaulted to 0 at first,
// and all images will be intersecting with the container.
// This will load all images at once, which will defy our purpose.

// NOTE2: transition:fade should NOT be dded to img element
// Instead, add an enclosing div, and add it to that div
// Otherwise, transitions don't work on image elements.

<div id="container">
 {#each images as image, index}
  <div bind:this={divs[index]} id={index} class="min-h-[300px]">
   {#if scrolls[index]}
    <div transition:fade={{ duration: 500 }}>
     <img src={image} class="h-[300px] object-contain" alt="An object" />
    </div>
   {/if}
  </div>
 {/each}
</div>

Now let's see whether above code will work in the container that we saw above:

Scroll to see all images

It does! And it looks fancy doesn't it. Now with the power of Svelte transition and Intersection Observer, you can create fancy lazy loaders.

Let's check whether the images are indeed lazy loaded:

You can see on the Chrome dev tools that, if the container is not scrolled, i.e. in its default scroll position, only 2 divs have images in them. And the remaining divs don't have any image in them.

So we can see that, we only loaded 2 images initially. If the user does not scroll, that will be it. If the user decides to scroll, we will be loading as the user scrolls. This is a user-centric and resource-saving approach to content serving.

Conclusion

Hope you can build a lazy loader with Svelte transitions and Intersection Observer after reading this. Let me know how it goes!

Happy hacking!
